Multicore LIYY Control cable
LIYY control cable; numbered cores, flexible PVC; −30 °C to +70 °C.
Item number: LIYY3075
Sales unit: 100 meter
Item number: LIYY3075C
Sales unit: 100 meter
Item number: LIYY4075
Sales unit: 100 meter
Item number: LIYY215
Sales unit: 100 meter
Item number: LIYY401
Sales unit: 100 meter
Item number: LIYY315
Sales unit: 100 meter
Item number: LIYY225
Sales unit: 100 meter
Item number: LIYY415
Sales unit: 100 meter
Item number: LIYY325
Sales unit: 100 meter
Item number: LIYY515
Sales unit: 100 meter
Item number: LIYY715
Sales unit: 100 meter
Item number: LIYY1215
Sales unit: 50 meter
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are marked in black (OZ) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are marked in black (OZ) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are marked in black (OZ) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are marked in black (OZ) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are marked in black (OZ) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are marked in black (OZ) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are marked in black (OZ) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are marked in black (OZ) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are marked in black (OZ) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are marked in black (OZ) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are numbered green/yellow + black (JZ)) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Product information
The control current cable is specifically designed for transmitting signal voltages in control cabinets and for operating onboard equipment on ships and vehicles. Available in a 2 x 0.75 mm² configuration and compliant with the VDE 0812 standard, this cable features solid copper conductors (Class 5) with PVC insulation. The outer sheath is grey, and the conductors are marked in black (OZ) for clear identification. With a nominal voltage of 300/500 V, a test voltage of 2 kV, and an operating temperature range from -30°C to +70°C, this control current cable is highly versatile. Variants are available in different cross-sectional areas (from 0.75 mm² to 2.5 mm²) and configurations to meet specific application requirements.
Data sheets
Specifications
| Number of conductors | : | 3 |
| Amperage (A) | : | 10 |
| Diameter in mm | : | 6.5 |
| Weight (kg/km) | : | 65 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 26 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 3 x 0,75 |
Specifications
| Number of conductors | : | 3 |
| Amperage (A) | : | 10 |
| Diameter in mm | : | 6.5 |
| Weight (kg/km) | : | 65 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 26 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 3 x 0,75 |
Specifications
| Number of conductors | : | 4 |
| Amperage (A) | : | 13 |
| Diameter in mm | : | 8 |
| Weight (kg/km) | : | 80 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 26 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 4 x 0,75 |
Specifications
| Number of conductors | : | 2 |
| Amperage (A) | : | 16 |
| Diameter in mm | : | 8.2 |
| Weight (kg/km) | : | 85 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 12.8 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 2 x 1,5 |
Specifications
| Number of conductors | : | 4 |
| Amperage (A) | : | 18 |
| Diameter in mm | : | 9.2 |
| Weight (kg/km) | : | 100 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 18 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 4 x 1 |
Specifications
| Number of conductors | : | 3 |
| Amperage (A) | : | 16 |
| Diameter in mm | : | 9 |
| Weight (kg/km) | : | 90 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 12.8 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 3 x 1,5 |
Specifications
| Number of conductors | : | 2 |
| Amperage (A) | : | 25 |
| Diameter in mm | : | 9.5 |
| Weight (kg/km) | : | 110 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 8.21 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 2 x 2,5 |
Specifications
| Number of conductors | : | 4 |
| Amperage (A) | : | 18 |
| Diameter in mm | : | 9.8 |
| Weight (kg/km) | : | 110 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 12.8 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 4 x 1,5 |
Specifications
| Number of conductors | : | 3 |
| Amperage (A) | : | 25 |
| Diameter in mm | : | 10.5 |
| Weight (kg/km) | : | 120 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 8.21 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 3 x 2,5 |
Specifications
| Number of conductors | : | 5 |
| Amperage (A) | : | 22 |
| Diameter in mm | : | 10.5 |
| Weight (kg/km) | : | 120 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 12.8 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 5 x 1,5 |
Specifications
| Number of conductors | : | 7 |
| Amperage (A) | : | 25 |
| Diameter in mm | : | 12 |
| Weight (kg/km) | : | 150 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 12.8 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 7 x 1,5 |
Specifications
| Number of conductors | : | 12 |
| Amperage (A) | : | 32 |
| Diameter in mm | : | 15 |
| Weight (kg/km) | : | 180 |
| Cable length | : | 100 |
| Class | : | Class 5 |
| Max temperature (°C) | : | 70 |
| Min temperature (°C) | : | -30 |
| Standard / specification | : | VDE 0812 |
| Ohm | : | 12.8 |
| RAL | : | 7001 |
| Temperature range | : | -30 - +70 |
| Test voltage | : | 2 kV |
| Cable type | : | Control cable |
| Cable type extra | : | LIYY |
| Flame retardant | : | Vlam vertragend |
| Flame spread | : | IEC 60332-1-2 |
| Operating voltage | : | 300 / 500 V |
| Wiring size in mm² | : | 12 x 1,5 |
12 versions
| No. | Stock | Bekabeling maat in mm² | Aantal aders | Amperage (A) | Diameter in mm | Gewicht (KG/KM) | Ohm |
|---|---|---|---|---|---|---|---|
| LIYY3075 | 3 x 0,75 | 3 | 10 | 6.5 | 65 | 26 | |
| LIYY3075C | 3 x 0,75 | 3 | 10 | 6.5 | 65 | 26 | |
| LIYY4075 | 4 x 0,75 | 4 | 13 | 8 | 80 | 26 | |
| LIYY215 | 2 x 1,5 | 2 | 16 | 8.2 | 85 | 12.8 | |
| LIYY401 | 4 x 1 | 4 | 18 | 9.2 | 100 | 18 | |
| LIYY315 | 3 x 1,5 | 3 | 16 | 9 | 90 | 12.8 | |
| LIYY225 | 2 x 2,5 | 2 | 25 | 9.5 | 110 | 8.21 | |
| LIYY415 | 4 x 1,5 | 4 | 18 | 9.8 | 110 | 12.8 | |
| LIYY325 | 3 x 2,5 | 3 | 25 | 10.5 | 120 | 8.21 | |
| LIYY515 | 5 x 1,5 | 5 | 22 | 10.5 | 120 | 12.8 | |
| LIYY715 | 7 x 1,5 | 7 | 25 | 12 | 150 | 12.8 | |
| LIYY1215 | 12 x 1,5 | 12 | 32 | 15 | 180 | 12.8 |
Related items
Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
This adjustable cable stripper is designed for cables with cross-sectional areas ranging from 4 to 28 mm², ensuring a clean strip without damaging the conductor for optimal performance.
This crimping tool is specifically designed for crimping insulated male and female cable lugs. Handling conductors from 0.5 to 6 mm², it delivers reliable performance and durability thanks to its robust steel construction.
Offers the same properties as the red variant – a versatile, self-extinguishing PVC tape for insulation and bundling. Suitable for a wide range of marine and automotive uses.
The Hotseal range, featuring fully insulated connectors and cable shoes, further ensures an extra waterproof and durable connection. These high-quality plugs and connectors provide the assurance required for demanding installations where safety and long-lasting performance are paramount. Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
Related items
Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
This adjustable cable stripper is designed for cables with cross-sectional areas ranging from 4 to 28 mm², ensuring a clean strip without damaging the conductor for optimal performance.
This crimping tool is specifically designed for crimping insulated male and female cable lugs. Handling conductors from 0.5 to 6 mm², it delivers reliable performance and durability thanks to its robust steel construction.
Ideal for general electrical insulation, bundling, and marking in boats, yachts, and cars. Self-extinguishing, flexible, and resistant to moisture and temperature variations.
The Hotseal range, featuring fully insulated connectors and cable shoes, further ensures an extra waterproof and durable connection. These high-quality plugs and connectors provide the assurance required for demanding installations where safety and long-lasting performance are paramount. Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
Related items
Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
This adjustable cable stripper is designed for cables with cross-sectional areas ranging from 4 to 28 mm², ensuring a clean strip without damaging the conductor for optimal performance.
This crimping tool is specifically designed for crimping insulated male and female cable lugs. Handling conductors from 0.5 to 6 mm², it delivers reliable performance and durability thanks to its robust steel construction.
Offers the same properties as the red variant – a versatile, self-extinguishing PVC tape for insulation and bundling. Suitable for a wide range of marine and automotive uses.
The Hotseal range, featuring fully insulated connectors and cable shoes, further ensures an extra waterproof and durable connection. These high-quality plugs and connectors provide the assurance required for demanding installations where safety and long-lasting performance are paramount. Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
Related items
Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
This adjustable cable stripper is designed for cables with cross-sectional areas ranging from 4 to 28 mm², ensuring a clean strip without damaging the conductor for optimal performance.
This crimping tool is specifically designed for crimping insulated male and female cable lugs. Handling conductors from 0.5 to 6 mm², it delivers reliable performance and durability thanks to its robust steel construction.
Ideal for general electrical insulation, bundling, and marking in boats, yachts, and cars. Self-extinguishing, flexible, and resistant to moisture and temperature variations.
The Hotseal range, featuring fully insulated connectors and cable shoes, further ensures an extra waterproof and durable connection. These high-quality plugs and connectors provide the assurance required for demanding installations where safety and long-lasting performance are paramount. Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
Related items
Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
This adjustable cable stripper is designed for cables with cross-sectional areas ranging from 4 to 28 mm², ensuring a clean strip without damaging the conductor for optimal performance.
This crimping tool is specifically designed for crimping insulated male and female cable lugs. Handling conductors from 0.5 to 6 mm², it delivers reliable performance and durability thanks to its robust steel construction.
Offers the same properties as the red variant – a versatile, self-extinguishing PVC tape for insulation and bundling. Suitable for a wide range of marine and automotive uses.
The Hotseal range, featuring fully insulated connectors and cable shoes, further ensures an extra waterproof and durable connection. These high-quality plugs and connectors provide the assurance required for demanding installations where safety and long-lasting performance are paramount. Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
Related items
Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
This adjustable cable stripper is designed for cables with cross-sectional areas ranging from 4 to 28 mm², ensuring a clean strip without damaging the conductor for optimal performance.
This crimping tool is specifically designed for crimping insulated male and female cable lugs. Handling conductors from 0.5 to 6 mm², it delivers reliable performance and durability thanks to its robust steel construction.
Ideal for general electrical insulation, bundling, and marking in boats, yachts, and cars. Self-extinguishing, flexible, and resistant to moisture and temperature variations.
The Hotseal range, featuring fully insulated connectors and cable shoes, further ensures an extra waterproof and durable connection. These high-quality plugs and connectors provide the assurance required for demanding installations where safety and long-lasting performance are paramount. Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
Related items
Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
This adjustable cable stripper is designed for cables with cross-sectional areas ranging from 4 to 28 mm², ensuring a clean strip without damaging the conductor for optimal performance.
This crimping tool is specifically designed for crimping insulated male and female cable lugs. Handling conductors from 0.5 to 6 mm², it delivers reliable performance and durability thanks to its robust steel construction.
Ideal for general electrical insulation, bundling, and marking in boats, yachts, and cars. Self-extinguishing, flexible, and resistant to moisture and temperature variations.
The Hotseal range, featuring fully insulated connectors and cable shoes, further ensures an extra waterproof and durable connection. These high-quality plugs and connectors provide the assurance required for demanding installations where safety and long-lasting performance are paramount. Our high-quality connectors and plug components are manufactured from durable materials such as brass and vinyl and meet stringent quality standards. The product range includes various types, such as flat plug housings, pin plugs, ring cable shoes, connectors, and conductor end boots – available in different sizes and colors (red, blue, yellow, etc.). Thanks to the use of high-quality plastic and precision engineering, these components deliver excellent electrical performance and reliable connections in a wide variety of applications, from industrial installations to marine and automotive projects.
Ask our experts
Our specialists are ready to advise you.
